class: center, middle # Hot Reloading with React and Redux github.com/robertknight/hot-reloading-talk .hint[Press 'P' for slide notes] ??? - This talk was originally called "Fast iteration on complex applications with Redux". - That's not very snappy. I'm going to try again - this is "Hot Reloading with React and Redux". - I'm expecting quite a mix of experience here, I'm going to try and make this accessible to people who are not familiar with React or Redux and hopefully there are some ideas here which might be useful even if you're not using either. --- class: middle ## Rob Knight @robknight_ github.com/robertknight Developer at [Hypothesis](https://hypothes.is) ??? - I'm a front-end developer at Hypothesis. We make an open source tool for collaboratively annotating web pages. - Before that I built native desktop apps for Mac, Windows and Linux. --- class: middle .center[![XKCD Compiling](https://imgs.xkcd.com/comics/compiling.png)] ??? - This talk is about something I had no idea how much I wanted until I tried it. - Building user interfaces is all about tweaking things, being able to make changes and see the effects quickly. - With static content and simple web apps, where you can express the state in the URL, this is pretty easy. You can set up something like BrowserSync or LiveReload to just reload the page when it detects a change to a file. --- class:middle .center[![Checkpoint Save](images/checkpoint-save.jpg)] ??? - With a more complex and stateful app, this doesn't work so well. After each tweak you spend a bunch of time getting the app back to the state it was before --- class: middle > **hot reloading** > > */hɒt/ /riːˈləʊd/* > > *n* Feature that lets you change styling and code in your app > and see the changes immediately without having to reload. ??? - Hot reloading is a feature that lets you change not just the styling, but most of your code, and see the results immediately without having to reload the page. - Popularized by React Hot Loader. Cool tech demo, but described by its creator as a hack. --- class: middle, center # Demo ??? - Demo app is a simple dashboard that lets you compare commit activity from different GitHub projects over the past year. - { Brief demo of functionality: Add chart, remove chart, zoom in } - { Point out that we have multiple charts, so not trivial to put state into URL } - { Hot reload demo: Increase height of zoomed-in chart } - { Hot reload demo: Tweak chart style } - { Hot reload demo: Tweak loading screen. This is where Redux comes in. } --- # Outline - How hot reloading works - Hot reloading views - Principles of Elm/Redux and how they enable hot reloading - Remaining challenges ??? - There are many boilerplate projects online that will give you a basic setup with Webpack/React/Redux that has hot reloading - Relying on boilerplate is OK, as long as it works flawlessly - This talk is going to focus on how hot reloading works under the hood and the how the principles behind Elm/Redux enable hot reloading and many other useful debugging and development tools. - React and Redux are well suited to hot reloading but you can still make use of the ideas even if you have a different stack. Redux in particular is not coupled to any view library. --- # Ingredients for Hot Reloading 1. Delivering code updates to the browser ??? - Three main things we need to do in order to implement hot reloading - The first is taking a code change to a file and getting it from disk to the browser -- 1. Updating views ??? - Once the app has the updated code available to it, it needs to load it somehow and update the components on screen to reflect those changes, preserving as much state as possible. - This is where Redux comes in -- 1. Preserving state, even if the model changes ??? - Lastly, if you make a change that affects the models in your app, we want to try and preserve as much state as possible --- # Delivering code updates to the browser ??? * The first part of enabling hot reloading is delivering code updates to the browser but only for the part of the app which changed. * Typically your application is divided into modules - views, models, services, utility code. These modules are then packaged into one or a small number of JavaScript files using Browserify or Webpack which the browser loads. * To go from editing code to updating the app, we need logic on the client and server. On the server, we need to generate an incremental update - effectively a mini-bundle that contains only the modules which changed. * On the client, we need to fetch and apply that update. * Implementations are available for Webpack and Browserify. If you have a new project, I'd recommend going with Webpack because this feature is part of the core and there is more documentation and sample code out there. --- .full-slide-img[![Module Tree](images/module-tree.svg)] ??? - App is divided into JS modules which `require()` other modules, with one of the modules designated as the entry point, forming a dependency graph. --- .full-slide-img[![Module Tree](images/module-tree-numbers.svg)] ??? - On disk the files require each other by name - In the bundle, each module is instead assigned a number and file names in `require()` calls are mapped to numbers --- class: middle Anatomy of a Webpack Bundle* ```js (function (modules) { /* bootstrap code */})([ function(module, exports, require) { /* module 0 (entry point) */ var dependency = require(1); var anotherDependency = require(2); ... }, function(module, exports, require) { /* module 1 */ }, function(module, exports, require) { /* module 2 */ }, ... ]) ``` *_Browserify_ bundles are very similar ??? - The structure of a Webpack or Browserify bundle is actually really simple - one big IIFE. - Starts with a bootstrap function which creates the `require()` function and the module cache. - The module cache is an object that maps module numbers to module functions. A module function is your original code for a module, wrapped in a function. - As soon as the bundle loads, the bootstrap function is called with an array of functions as an argument. - Each function is a module from your original code. - Modules reference each other by index in the array. - Hot updating involves removing any existing entry from the module cache and replacing it with the function object for the updated module. - Updates need to be applied in the right order --- Enabling hot reloading on the client ```js webpack --hot ``` * Enables the 'Hot Module Runtime' plugin * This adds an extra chunk of code to the bootstrap (the "HMR runtime") * Provides functions for checking for updates and updating the module cache. --- Initial build: ```sh *Hash: 015b66e9275f10ef1b86 Version: webpack 1.12.12 Time: 2698ms Asset Size Chunks Chunk Names bundle.js 1.06 MB 0 [emitted] main ``` In bundle.js: ```js ... var hotApplyOnUpdate = true; *var hotCurrentHash = "015b66e9275f10ef1b86"; var hotCurrentModuleData = {}; var hotCurrentParents = []; ... ``` ??? - When the client checks for updates, it needs to indicate which version of the code it currently has, so it can download the right changes. - When Webpack builds a bundle, it generates a compilation hash. This hash is embedded in the bundle itself. - When checking for updates, Webpack will look for a JSON file on the server whose name includes the hash. --- After a code change: ```sh Hash: b444a862c30a14d36321 Version: webpack 1.12.12 Time: 318ms Asset Size Chunks Chunk Names bundle.js 1.06 MB 0 [emitted] main 0.015b66e9275f10ef1b86.hot-update.js 3.9 kB 0 [emitted] main 015b66e9275f10ef1b86.hot-update.json 36 bytes [emitted] + 427 hidden modules ``` Update manifest: CURRENT_HASH.hot-update.json ```js {"h":"b444a862c30a14d36321","c":[0]} ``` Update content: CHUNK_ID.CURRENT_HASH.hot-update.js ```js webpackHotUpdate(
, {
: function(module, exports, require) { // your new module code } }); ``` ??? * When you make a code change, Webpack will perform an incremental build and if hot-module-reloading is enabled, it will also generate an _update manifest_ and _update chunk_ * The update manifest's name includes the previous compilation's hash, so the client can fetch it. Inside the manifest is the hash of the current compilation * The compilation hashes link together the updates in a chain, enabling the client to fetch and apply them in the right order * The update chunk is a mapping of module IDs to updated code for that module --- # The client API ```js // Exists if the hot reloading runtime is available module.hot = { // Attempt to fetch an update manifest check() // Register a handler to be invoked // when 'dependency' or one of _its_ // dependencies is updated accept(dependency, callback) // Register a handler to be called // when the module is unloaded addDisposeHandler(callback) } ``` ??? - If a module is built with hot reloading enabled, an additional `hot` property is added to the module object. - Modules can use these to initiate a check for updates and also declare that they can accept updates for dependencies. --- .full-slide-img[![Update Check](images/update-check.svg)] ??? - When the client receives an update, it marks each of the updated modules as outdated - Each of the parents of that module is queried to see whether it can accept an update for that dependency, registered with `module.accept()` - If the parent can accept the update, the parent's `module.accept()` callback is invoked. --- .full-slide-img[![Update Check](images/update-check-2.svg)] ??? - If not, the parent itself is marked as outdated and the search continues up the tree, until we get to the root. - In this case, 3 cannot handle updates for 7 itself, so the search continues up to the entry module. - Module 0 _can_ handle the update and it will `require()` the new version of module '3', which will also load the new version of module '7' in the process. --- # Updating Views ??? - So given the ability to load a new version of some code for a UI component, in order to hot-reload it, we need to update all of the DOM elements in the app to reflect the new version. - React makes this easy --- class:middle React components are functions that return an object _describing_ what should be in the DOM. ```js function Button(props) { return
Click me
; } ``` is equivalent to... ```js function Button(props) { return { type: 'button', props: { onClick: props.onClick, children: 'Click me', }, // a few other fields omitted } } ``` ??? - In a traditional MVC framework, replacing a component is a tricky thing to do - You'd have to find all instances of a component on screen, remove their DOM elements, generate new ones using the updated code and insert them back in place. - React components on the other hand are simply functions that return an object describing what the DOM should look like and what event handlers should be attached. - This makes hot reloading much easier --- # Updating views App.js ```js module.exports = function () { return
Hello World
; } ``` index.js ```js var App = require('./App'); ReactDOM.render(
, document.getElementById('root')); *module.hot.accept('./App', function () { App = require('./App'); ReactDOM.render(
, document.getElementById('root')); }); ``` ??? - This is the "hot reloading" Hello World with React --- class:middle - If you are using Babel, the `react-transform-hmr` plugin can be used to rewrite your code at compile time to add `module.hot` calls and reload the component - Caveat: `react-transform-hmr` does not yet support stateless function components. ??? - The reason why 'react-transform-hmr' does not support function components is interesting. --- class: middle - So that deals with updating the views, but how do we preserve the state of the application? - What if we want to make changes to models as well as views? - This is where Redux comes in --- class: middle - Inspired by _Elm_, a functional compile-to-JavaScript language. - Components in Elm are stateless, just a collection of 3 functions ??? - Redux started as a project to enable hot reloading in a robust way. --- class: middle .large-slide-img[![Elm Component](images/elm-component.svg)] ??? - Redux is inspired by Elm and in particular a way of structuring a UI referred to as the 'Elm architecture'. - A UI component in Elm consists of 3 pure functions: One to get the initial state for the component, one that takes the state and returns a description of the UI to render given that state and finally one to get the new state given the current state and an action. - An 'action' is something like a mouse click, or a WebSocket message - Important to notice for hot reloading: Component is entirely pure. Contains the logic to manage the state but doesn't store it. Therefore, to do a hot reload, we just need to change the arrows on the left to point to the new version. --- .large-slide-img[![Elm Component](images/elm-component-reload-1.svg)] ??? - Since the component is pure, in order to replace it with a new version at runtime, all we need to do is redirect the input arrows that feed state updates and the action signal into it to point to the new version --- .large-slide-img[![Elm Component](images/elm-component-reload-2.svg)] --- class: middle .large-slide-img[![React/Redux Component](images/react-redux-component.svg)] ??? - By constrast, this is the architecture of React/Redux - The data flow is the same. The main difference is that whereas in Elm the three functions are part of the same component, here the view part is React, the update/init parts are merged together into a single 'reducer' function in Redux - The view and reducer components are still pure, so hot reloading works the same way --- # Three Basic Principles 1 - Store all of your application's state in a single, immutable object. ```js { charts: [{ repository: 'facebook/react', isLoading: false, data: [...], }, ... ], focusedChart: 0, } ``` _Better yet: Make it a **plain JavaScript object**_ ??? - The first principle is that the state of your app is stored in a single, immutable object, separate from the logic that updates it. - This enables a lot of useful debug tools on its own. For example, you can easily expose the store as a property on the 'window' object for easy inspection in dev tools. {Show state in demo app} - Why immutable? That enforces that there is only one way to update it. --- 2 - The only way to change the state is by calling a `dispatch()` function with an 'action', which is just a plain JavaScript object describing what happened. ```js function setRepository(name) { return { type: 'SET_REPOSITORY', repository: name, }; } // in the 'onSubmit' handler for the form where the user // chooses a repository to view store.dispatch(setRepository(name)); ``` --- 3 - State updates are made by a collection of functions (called 'reducers'), which take the current state, the action and return the new state. ```js var initialState = { repository: undefined, }; function chart(state, action) { switch (action.type) { case 'SET_REPOSITORY': return Object.assign({}, state, { repository: action.repository, }); default: return state || initialState; } } ``` ??? - State updates happen by calling a function on the store, `dispatch()` and passing it an object describing what happened. - In our example app, we have actions for the user selecting a repository, data being fetched from the GitHub API and the user zooming into or out of a chart. {Show actions in debug tools} --- # The Redux API ```js createStore(reducer, initialState); store: { dispatch: function(action) { // call reducer(getState(), action) and replace // the state with the result }, subscribe: function(listener) { // add a listener which will be called whenever the // state changes }, getState: function() { // returns the current state of the application }, replaceReducer: function (reducer) { // replace the 'reducer' function, this enables // live code updates } } ``` ??? - The basic API of a store is extremely simple. Call `createStore()` and get back an object with functions to get the current state of the app, list for state changes, and dispatch actions to trigger state changes. --- # Poor man's hot reloading - Persist state to `window.localStorage` or `window.hash` - Restore on load ```js var initialState = JSON.parse(atob(window.location.hash.slice(1)) || 'null'); var store = redux.createStore(rootReducer, initialState); store.subscribe(function () { window.location.hash = JSON.stringify(btoa(store.getState())); }); ``` ??? - By storing all our app state in a single object, we can already implement a simple hot reloading hack. - Every time the app state changes, we'll serialize it and put it in `window.hash` - If we reload the app, we'll deserialize that state. {Let's go and try it out!} --- # Hot Reloading with Redux ```js var reducer = require('./rootReducer'); if (module.hot) { module.hot.accept('./rootReducer', function () { reducer = require('./rootReducer'); store.replaceReducer(reducer); }); } ``` ??? - Redux provides a `replaceReducer()` API which lets you replace the reducer function. - If you have the dev tools enabled, all of the actions will be replayed, allowing you to see the effects of reducer changes live. - { Demo fixing bug when resetting repo whilst zoomed in } --- # Challenges ??? - This covers the basics, now I'll take a look at aspects of hot reloading and React/Redux which are still maturing and problems you might run into. --- # Error handling ??? - This is JavaScript. It may shock you to learn that even after Babel compiles it, it may still have bugs. - What happens if an exception is thrown whilst trying to load the new code? -- - React will get stuck in a broken state if component render function throws - Wrap `render()` method to catch errors and render a fallback instead. - The `react-transform-catch-errors` Babel plugin will do this for you - Improvements ("error boundaries") coming in v0.15 ??? - Out of the box, React currently does not cope very well. - If a component throws an error whilst rendering, React will get stuck in an invalid internal state where subsequent renders will fail. - Fortunately, since components are just functions, you can wrap them with another function which catches the exception and renders something else. {DEMO} --- class: middle ```js function catchErrors(Component) { var wrapped = function () { try { // try to render the component normally return Component.apply(this, arguments); } catch (err) { // something went wrong, replace it with a big red box // displaying the error message and stack trace return
; } }; wrapped.displayName = Component.name; return wrapped; } MyComponent = catchErrors(MyComponent) ``` ??? {Live demo of error handling} --- - Redux on the other hand copes much better - If a reducer throws, you just get the previous state back ```js // createStore.js function dispatch(action) { ... try { isDispatching = true currentState = currentReducer(currentState, action) } finally { // ... something went wrong, currentState will simply // remain unchanged isDispatching = false } ... } ``` ??? - Thanks to the store being immutable and state changes happening via pure functions, Redux copes much better. - If a reducer throws, the state remains unchanged. You can then just fix your code and reload the app - If a bug results in corrupt state in the store, you can fix this by replaying all of the actions. --- # State outside your app and the DOM - `setInterval()` - Async sequences ??? - In event handlers, you might kick off a series of async actions which might dispatch actions as a result. - Changes to this code typically isn't reflected until the next time you trigger the action. --- # Summary - Hot reloading is a useful productivity tool, but really just one of many productivity/debugging tools enabled by the architecture - Robust hot reloading is not just a build system feature, needs an app architecture that separates state and logic --- class: middle github.com/robertknight/hot-reloading-talk Rob Knight @robknight_ ??? - Code for the example app is up on GitHub. It is intended as an explanation for how things work rather than code you should copy and paste into a new project. - Also, inevitable plug. If you find this topic interesting, Hypothesis is hiring an interface developer. Come talk to me!
